ProFusion Countertop System
N2 Beverages on Tap
- Nitrogenated and Still Beverage on Tap.
- Flash chills ambient temp keged beverages.
- The system utilizes one keg of cold brew coffee, tea or your craft beverage of choice to dispense two different style beverages.
- Simple set-up: one keg connection and one gas connection.
- Integrated ProFusion injector nitrogenates the beverage at the time of dispense.
- Two integrated secondary regulators feed both the keg and injector pressures.
- Built in 50 mesh stainless steel strainer, washable and reusable.
- Optional custom tap handles available.
Specifications
- 30, 12 oz cups per hour @<40F
- Self-contained refrigeration system
- Compressor: 1/9 H.P.
- Refrigerant: R134a CFC-free
- Ambient Operating air temperature: 40F-100F
- Electrical: 120VAC/60Hz/1 Phase
- 2.8 AMPS
- Minimum circuit breaker size: 15 amps
- Water bath: 2.5 gallons
- Ice bank: 6 lbs
- Weight: 75
- Cup clearance: 8.5”
- 12”W x 26”D x 21.5”H*
- Air intake at rear with air filter
- Allow 4 inch rear and side clearance for airflow
- 6 ft overflow drain hose
- 9 ft electrical cord NEMA 5-15
- 4.25 inch legs
- * Actual height varies depending on tap handle style
